Invoice checkout

Flowchart

Source:
https://cahskuy.stoplight.io/docs/OND/3c78799259e69-payment-checkout

Reference:
Transaction Flowchart

Endpoint
Endpoint Method
 Authentication
/payment-checkout
 POST Yes
Authentication
Type
 Token source
 Server
 Description
Bearer {{usapi}}/auth USAPI Buyer's auth
Body request example
{
    "total_amount": 40000,
    "service": "ONMARKET",
    "source": "XENDIT",
    "transaction": [
        {
            "amount": 10000,
            "freight_charge": 5000,
            "insurance_amount": 100,
            "commission_onmarket": 1000,
            "seller_username": "testing123",
            "invoice_onmarket": "INV/ONM/20240124-002B0001"
        },
        {
            "amount": 20000,
            "freight_charge": 5000,
            "insurance_amount": 100,
            "commission_onmarket": 1000,
            "seller_username": "testing12345",
            "invoice_onmarket": "INV/ONM/20240124-002B0002"
        }
    ]
}
Properties
 Properties of Data type Required Description
total_amount
integer yes Total nominal amount for the invoice.
service
string yes

ONINDONESIA services.
Possible values:

  • ONDELIVERY means the source of the transaction comes from ondelivery.
  • ONTICKET means the source of the transaction comes from onticket.
  • ONMARKET means the source of the transaction comes from onmarket.
source
string yes A way that users pay for a product or service. Possible values: XENDIT, BALANCE, QRIS.
transaction   array<object> yes List of transactions.
amount transaction integer yes Amount of transaction for each store (do not include freight charge and insurance as they'll put in other parameter).
freight_charge transaction integer yes Amount of freight charge for each store.
insurance_amount transaction integer no Amount of insurance for each store.
seller_username transaction string yes Seller ONMARKET username
invoice_onmarket transaction string yes Invoice ID generated by ONMARKET
commission_onmarket transaction integer yes Commission amount charged to seller
Response example

200 (OK)

Example response for ONMARKET

{
    "payment_url": "https://checkout-staging.xendit.co/latest/65ba1b78f603539c068ef753",
    "invoice": "ONM0001N11V0000x",
    "xendit_invoice": "65ba1b78f603539c068ef753",
    "expired_at": "2024-01-31T12:05:44.155Z",
    "transaction": [
        {
            "invoice_onmarket": "INV/ONM/20240124-002B0001",
            "status": "PENDING"
        },
        {
            "invoice_onmarket": "INV/ONM/20240124-002B0002",
            "status": "PENDING"
        }
    ]
}
Properties
 Properties of Data type Description
xendit_invoice
string invoice ID generated by XENDIT and translated by USAPI
payment_url
string

Public URL for this invoice
expired_at
timestampz

ISO date and time that the invoice expires.
transaction
array<object>

List of transactions
invoice transaction string

Invoice ID generated by USAPI
status transaction string

Status showing whether the invoice has been paid

Possible values:

  • PENDING means the invoice has been successfully created but yet to be paid
  • PAID means the invoice has been paid
  • EXPIRED means the invoice expired before your customer paid



Example for response ONMARKET with source QRIS

{
    "invoice": "ONM00001N14U00001",
    "xendit_invoice": "qr_7807d58a-3d60-4425-92f9-23d6717701f6",
    "qr_string": "00020101021226570011ID.DANA.WWW011893600915060486424802096048642480303UKE51440014ID.CO.QRIS.WWW0215ID20243148326170303UKE52048999530336054031005802ID5925PT OnIndonesia Sistem Tek6015Kota Jakarta Ut61051424062720115NT2YP2fE3fetkbx60490011ID.DANA.WWW0425MER2021071400774509608641050116304DE92",
    "amount": 100,
    "expired_at": "2024-04-30T05:00:52.643Z"
}
Error response

400 Bad Request

Some parameters may contain invalid values or some parameters are not present.
{
    "message": "Invalid JSON Format"
}

Balance is not enough for doing transaction

{
    "message": "Insufficient balance"
}

401 Unauthorized

Authentication header is not valid or missing
{
    "message": "Auth Error"
}

500 Internal server error

Internal server error
{
    "message": "Internal server error"
}
